Dehn

Phase screw clamp D 10-65mm T-pin shaft connec. elem. PK1 16-120mm? w. coupl. aid Phase screw clamp with coupling aid and long threaded T pin shaft for connecting the phase cables of earthing and short-circuiting devices to the overhead line in accordance with EN/IEC 61230 (DIN VDE 0683-100). PK1 anti-rotation element

Enkelpolige gecoördineerde modulaire bliksemstroomafleider N-PE. Max. toelaatbare continue spanning: 440Vac.

Voltage detector PHE4 1...3kV 50Hz Category S Capacitive PHE4 voltage detector in accordance with EN/IEC 61243-1 (DIN VDE 0682-411) for verifying safe isolation from supply voltage on all poles at the work location in accordance with EN 50110-1 (DIN VDE 0105-100) in electrical installations. Category "S" for switchgear installations and overhead lines. Suitable for use in wet weather conditions. With visual and acoustic indication and self-testing element of all active parts including test prod. Short transport length due to unscrewable insulating stick with plug-in coupling for extending the handle

Gecombineerde overspanningsafleider en netfrequente overspanningsbewaker. Voor driefasige installaties (3x400V + N) t.e.m. 32A

Arc-fault-tested protective jacket ""Indoor"", APC 2, size: 52 (M/L) DEHNcare APJ ID arc-fault-tested protective jacket with stand-up collar and useful pockets for maintenance and repair work on electrical installations in indoor areas. Certified according to the requirements of the PPE regulation (EU) 2016/425. Single-layer fabric ensures high wearing comfort. Reflective strips for better visibility. Different colour combinations and customised versions are possible. Box test in accordance with IEC 61482-1-2, EN ISO 11612, EN 1149-5.

Elastic belt Flame-resistant, length: 120 cm Elastic belt, flame-retardant for arc-fault tested protective pants APT ID/OD.

DEHNguard M TN 150 FM tweepolige modulaire overspanningsbeveiliging voor monofasig TN netsysteem. Type 2 afleider volgens EN61643-11. Nom afleidstootstroom 15kA(8/20). Beveiligingsniveau 0,7kV. Met afstandsmeldcontact.

DEHNguard S 75 FM enkelpolige overspanningsafleider, tweedelige opbouw, bestaande uit basisdeel en insteekbare beveiliging. Maximum toelaatbare bedrijfsspanning 75V AC. Nom afleidstootstroom : 10kA(8/20). Beveiligingsniveau 0,4 kV. Met afstandsmeldcontact (potentiaalvrij wissel).

Aardingsbeugel voor het verbinden van vb. 3 overspanningsafleiders (in behuizing 3 modulebreedte). Met aansluitklem voor de aarding.

DEHNguard M TT 275 vierpolige modulaire overspanningsbeveiliging voor TT netsysteem. Type 2 afleider volgens EN61643-11. Nom afleidstootstroom 20kA(8/20). Beveiligingsniveau 1,50kV.

Bolted-type connector with M12 threaded bolt L 55mm and nut Bolted-type connector with threaded pin and loose hexagon nut as connection point to the earthing system in accordance with EN/IEC 61230 (DIN VDE 0683-100)

Voltage detector PHE4 30kV 50 Hz with gear coupling Category S Capacitive PHE4 voltage detector in accordance with EN/IEC 61243-1 (DIN VDE 0682-411) for verifying safe isolation from supply voltage on all poles at the work location in accordance with EN 50110-1 (DIN VDE 0105-100) in electrical installations. Category "S" for switchgear installations and overhead lines. With universal gear coupling in accordance with EN/IEC 60832 (DIN VDE 0682-211). Suitable for use in wet weather conditions. With visual and acoustic indication and self-testing element of all active parts including test prod. Short transport length due to unscrewable insulating stick with plug-in coupling for extending the handle

DEHNgap MAXI 1 255 S gecoördineerde enkelpolige N-PE bliksemstroomafleider voor directe montage op barenstel. Type 1 volgens EN61643-11. Afleidstootstroom 100kA(10/350). Beveiligingsniveau 2,5 kV.

Ball head cap, 16-120mm?, D=20mm Rigid ball head cap with long T pin shaft for use as phase or earth connecting element in accordance with EN/IEC 61230 (DIN VDE 0683-100) for fixed ball points for connecting the phase cables of earthing and short-circuiting devices. PK1 anti-rotation element

Insulating stick 36kV w. plug-in coupling T pin shaft L 1000mm Insulating stick in accordance with E DIN VDE V 0681-1,T pin shaft. Operating head with bayonet locking mechanism and pressure spring. For use as switching stick and operating stick by attaching a SSK SQ switching stick head, operating stick for inserting insulating protective shutters or earthing stick. End fitting with anti-rotation plastic plug-in coupling for extending the handle

Arc-fault-tested protective trousers ""Outdoor"", APC 2, size: 54 (L) Arc-fault-tested protective trousers DEHNcare APT OD for maintenance and repair work on outdoor electrical installations. Certified in compliance with the PPE regulation (EU) 2016/425 on personal protective equipment. Very comfortable to wear due to single layer material. Reflective strips ensure excellent visibility. Box test as per IEC 61482-1-2, EN ISO 11612, EN 1149-5, EN 13034 (PB 6), EN ISO 20471. Arc Rating - ATPV (Open Arc Test): 16 cal/cm².

DEHNrail Modular M 2P 60. Tweepolige overspanningsafleider type 3 volgens EN61643-11. Steekbare uitvoering. Nom. afleidstootstroom 1kA(8/20). Beschermingsniveau = 350V.

Kamrail, 4fasig, 56-polig. Voor het aansluiten van fasegeleiders op overspanningsbeveiliging.

Gecoördineerde enkelpolige bliksemstroomafleider voor DC toepassingen.

Earthing stick for hexagon shafts w. plug-in coupling L 2000mm Single-part earthing stick with hexagon shaft. Operating head with spring locking mechanism for approaching and attaching portable earthing and short-circuiting devices safely to electrical installations for earthing and short-circuiting purposes according to EN 50110 (DIN VDE 0105-100). Handle termination with anti-rotation plastic plug-in coupling for easy and safe handle extension

Plugin compacte gecombineerde bliksem- en overspanningsafleider met Lifecheck voor de beveiliging van 2 aders met gemeenschappelijk referentiepotentiaal en asymmetrische interfaces. Modulebreedte van slechts 6mm. Aansluitklemmen met Push-in veertechniek en voorzien van visuele statusindicatie. Een defecte afleider onderbreekt het signaal niet (fail open). Nom. spanning Un = 12V. Toepasbaar in het bliksembeveiligingszoneconcept aan zone-overgang 0A naar 2 en hoger.
